Diavel V4

Starting from £23,595.00

Enquire about this model

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry
Return to Model Categories

Model Promotions

Find out more

Description & Specification


Dare to be Bold

Muscular, sporty, exaggerated and elegant at the same time, able to magnetize attention in any context, Diavel V4 synthesizes seemingly distant technical, dynamic and stylistic features, such as those of sport nakeds and muscle cruisers.
The exhilarating performances of the V4 Granturismo engine are combined with surprising agility and dynamics for such a motorcycle.

Designed around the V4 Granturismo

Muscular, gritty, with its broad “shoulders” and proudly visible four-exit exhaust, the Diavel V4 is designed to convey boldness and not go unnoticed. Starting with the new front and rear light cluster, to the retractable passenger footpegs and the retractable rear grab bar are the details that make the difference and make the design of this bike even more unique and unmistakable.

Unmistakable design.Unique personality.

Muscular, gritty, with its broad “shoulders” and proudly visible four-exit exhaust, the Diavel V4 is designed to convey boldness and not go unnoticed. Starting with the new front and rear light cluster, to the retractable passenger footpegs and the retractable rear grab bar are the details that make the difference and make the design of this bike even more unique and unmistakable.

  • Frame

    Frame

    Tubular steel Trellis frame

    Rake

    27°

    Front Wheel

    Light alloy cast 3.5"x17"

    Front Tyre

    Pirelli Diablo Rosso III 120/70 ZR17

    Rear Wheel

    Light alloy casted 8.0"x17"

    Rear Tyre

    Pirelli Diablo Rosso III 240/45 ZR17

    Fuel Tank Capacity

    17l - (4.5 US gal)

    Dry Weight

    223 kg (492 lb)

  • Dimensions

    Wheelbase

    1600mm (63 in)

    Front Wheel Travel

    120mm (4.7in)

    Rear Wheel Travel

    130mm (5.1in)

    Seat Height

    780 mm (30.7 in)

    Bore x Stroke

    106 x 71.5 mm

    Compression Ratio

    13.0 : 1

  • Suspension

    Front Suspension

    Ø 50 mm adjustable usd fork

    Rear Suspension

    Monoshock, preload and rebound adjustable, Aluminium casted single-sided swingarm

  • Brakes

    Front Brake

    2 x Ø 320 mm semi-floating discs, Radially mounted Brembo monobloc 4-piston M4.32 callipers, PR18/19 radial master cylinder, Bosch Cornering ABS Evo

    Rear Brake

    Ø 265 mm disc, 2-piston Brembo floating calliper, Bosch Cornering ABS Evo

  • Performance

    Engine Type

    Ducati Testastretta DVT 1262, L-Twin cylinder, 4 valves per cylinder, Dual Spark, Liquid cooled, Desmodromic Variable Timing

    Displacement

    1,262 cc (77.0 cu in)

    Power

    162 hp (119 kW) @ 9,500 rpm

    Torque

    129 Nm (95 lb-ft, 13.1 kgm) @ 7,500 rpm

    Exhaust

    Stainless steel pipes and single muffler with twin tail pipes, Catalytic converter and 2 lambda probes.

    Gearbox Type

    6 speed

    Gearbox Ratio

    1=37/15, 2=30/17, 3=27/20, 4=24/22, 5=23/24, 6=22/25

    Primary Drive

    Straight cut gears, ratio 1.84:1

    Final Drive

    Chain, Front sprocket Z15, Rear sprocket Z43

    Clutch

    Slipper and self-servo wet multiplate clutch with hydraulic control

    Battery
