Description & Specification


I M Legend

Monster reinvents itself. The fifth generation brings a fresh guise and a new heart: an updated design, the new V2 twin engine and cutting-edge electronic technologies.
The continuous evolution of a spirit that has never changed, a legend that has put generations of motorcyclists on the road.
Just as it did thirty years ago, Monster continues to embody the very essence of Ducati.

An icon that continues to evolve

Modernity and heritage interweave in a continuous dialogue, in the most technological Monster of all time. A bike designed down to the finest details, that retains the same spirit it had when it changed Ducati forever: simple, pure and immediately recognisable.

  • Frame

    Frame

    Monocoque Aluminium

    Rake

    23.3°

    Front Wheel

    Casted light alloy, 3.50" x 17"

    Front Tyre

    Pirelli Diablo Rosso III 120/70 ZR17

    Rear Wheel

    Casted light alloy, 5.50” x 17”

    Rear Tyre

    Pirelli Diablo Rosso III 180/55 ZR17

    Fuel Tank Capacity

    14 l (3.7 US gal)

    Dry Weight

    166 kg (366 lb)

  • Dimensions

    Wheelbase

    1,492 mm (58.7 in)

    Front Wheel Travel

    130 mm

    Rear Wheel Travel

    145 mm

    Seat Height

    815 mm (32,1 in), 795 mm (31,3 in) with low seat accessory, 775 mm (30,5 in) with low seat accessory + low suspension kit

    Bore x Stroke

    96 mm x 61.5 mm (3.8 in x 2.4 in)

    Compression Ratio

    13.3:1

  • Suspension

    Front Suspension

    Showa Ø 43 mm usd fork

    Rear Suspension

    Showa monoshock with adjustable preload. Aluminium double-sided swingarm

  • Brakes

    Front Brake

    2 x Ø 320 mm semi-floating discs, radially mounted Brembo M4.32 monobloc 4-piston callipers, radial master cylinder, Cornering ABS.

    Rear Brake

    245 mm disc, 2-piston caliper. Cornering ABS

  • Performance

    Engine Type

    Ducati V2 engine: 90° V2, 4 valves per cylinder, intake variable valves timing system, liquid cooled

    Displacement

    890 cc (54.3 cu in)

    Power

    111 hp (81.6 kW) @ 9,000 rpm

    Torque

    91.1 Nm (9.3 kgm, 67 lb ft) @ 7,250 rpm

    Exhaust

    2-1-2 system

    Gearbox Type

    6 speed with Ducati Quick Shift up/down 2.0

    Gearbox Ratio

    1=38/14 2=34/17 3=32/20 4=29/22 5=24/21 6=26/25

    Primary Drive

    Straight cut gears; Ratio 1.84:1

    Final Drive

    Chain 520; front sprocket 16; rear sprocket 42

    Clutch

    Hydraulically controlled slipper and self-servo wet multiplate clutch. Self bleeding master cylinder

    Battery
